Surface Mount Equipment and specifications:

Board Size Min = 50 mm x 50 mm (2” x 2”)
Board Size Max = 508 mm x 508 mm (20” x 20”)

• 2 - EKRA X4 screen printers
• 2 - EKRA Serio 4000 volume printers
• 2 - Parmi SigmaX Blue solder paste inspection
• 2 - Samsung SM481 placement systems
• 1 - Samsung SM482 placement system
• 2 - Samsung SM421 placement systems
• 1 - Samsung SM485 placement system
• 1 - Samsung SM411 placement system
• 1 - Samsung SRF70i123 reflow oven
• 2 - BTU Pyramax reflow ovens (models 98 & 125)

Ball Grid Array and Advanced SMD’s

BGA’s (BGA placement up to 55mm² 1.0mm pitch)

• ERSA HR600/2

• µBGA (0.5mm pitch)
• Ultrafine pitch components (0.4mm pitch)
• QFN/MLP
• LGA
• CSP
• 01005 chip components
• Odd Form components
• Large Connectors (up to 72mm diag.)

Wave and Selective Soldering – Lead or Lead Free (RoHS)

• Electrovert Vectra Elite
• Vitronics Soltec Delta 5
• ERSA Powerflow

• ESRA VERSAFLOW 3/66 (2.5” x 5” min) (24” x 24” max)
• Apollo Seiko L-CAT 4540 Robotic Solder System
• 1 - Seho Selectline C Soldering Machine
  Board Size Max = 500mm x 500mm (19.68” x 19.68”)
• 2 - ERSA Smartflo 2020 Selective Soldering Machines (Max 18” x 24”)

Through-Hole assembly equipment

Board Size Min = 50 mm x 50 mm (2” x 2”)
Board Size Max = 350 mm x 460 mm (14” x 18”)

• 6 - Contact Systems CS-400 Component Locators

Inspection

Automated Optical Inspection

Board Size Min = 50 mm x 50 mm (2” x 2”)
Board Size Max = 510 mm x 660 mm (20” x26”)

• 2 - Mirtec In-Line MV-6 Omni 3D
• 1 - Mirtec In-Line MV-7U
• 1 - Mirtec In-Line MV-7xi
• 2 - Mirtec Desktop MV-2HTL
• Intelli-Scan Laser inspection

X-Ray Inspection

• Nikon XT V160 X-Ray Inspection station
• FeinFocus Yxlon Y. Cougar X-Ray Inspection station

Automated Depaneling

• Cencorp 1000BR – depaneling and high-capacity router

Cleaning

Board Size Min = n/a
Board Size Max = 24 x 25”

• Technical Devices Nu/Clean 824 XLR-FB Inline Aqueous Wash Machine

PCB Conformal Coating and Potting

PCB Conformal Coating

• PVA6000 Conformal Coating Machine and IR2000 Curing Oven
  Acrylic  /  Urethane  /  Silicone  /  Polyurethane

• Fisnar 3 Axis Dispensing Robot

Circuit Board Testing

• SPEA Flying Probe
• 2 - Teradyne LH In-Circuit Test Stations
• Functional testing on customer owned fixtures
• Custom Test Fixture Designs

Supporting Equipment

• N-150 TGN Nitrogen Generator
• Optical Control OC Scan CCX.3 Component Counter
• High Voltage Soldering
• Insignum 4000 Automatic Laser Marking System
• Barcodes Part Marking Barcode Reader System
• MakerBot 3D Extrusion Printer
• Vayo NPI 3D DFM Software

We invest in Technology that keeps Altek’s facility running efficiently, allowing us to consistently provide the best possible product to our customers.
